Architectural Wall Panels
/
Illumination

Illumination

Designer Series
  • Custom Colors Available with Nichiha’s Color Xpressions Technology
  • Smooth, Semi-gloss Finish
  • Delivers a Sleek Sophisticated Look
Features
  • Design Versatility
  • Backed by Nichiha’s Advanced Clip System
  • Built-in Rainscreen
Specifications
Illumination: AWP 1818
Dimensions (Actual MM)
455 H x 1818 L
Dimensions (IN.)
17 7/8 H x 71 9/16 L
Thickness (Actual MM)
16
Thickness (IN.)
5/8
Weight (LBS. Per Panel)
35.2
Weight (LBS. Per SQ. FT.)
3.9
Exposed Coverage (SQ. FT. Per Panel)
8.88
Packaging (Piece Per Pack)
2 [17.76 SQ. FT.]
Panel Orientation
Horizontal
Custom Color Available
Yes
Illumination: AWP 3030
Dimensions (Actual MM)
455 H x 3030 L
Dimensions (IN.)
17 7/8 H x 119 5/16 L
Thickness (Actual MM)
16
Thickness (IN.)
5/8
Weight (LBS. Per Panel)
57.2
Weight (LBS. Per SQ. FT.)
3.8
Exposed Coverage (SQ. FT. Per Panel)
14.81
Packaging (Piece Per Pack)
2 [29.62 SQ. FT.]
Panel Orientation
Horizontal or Vertical
Custom Color Available
Yes
CAD Details
Product Specs
Product Support
Design Review Guide
Install Documents 1818
Install Documents 3030:   Horizontal   Vertical
Install Videos
Product Catalogs
Get a Sample
Contact a Rep
See More

Additional Products
Customers Also Viewed

ArchitecturalBlock
arrow_forward
Miraia
arrow_forward
Ribbed
arrow_forward
VintageWood
arrow_forward

Nichiha Illumination Panels Add Color to Minneapolis Landscape

Urbanworks’ architects talk designing with color and custom color Illumination panels for adding bold designs to touches to project in this informative Nichiha vlog.

Custom Color Innovation

Illuminate your design with custom color using Nichiha Color Xpressions technology

Sleek Sophistication

Elevate your building facade with a smooth, polished finish using Illumination panels
